Domane SLR 9 AXS is our top-of-the-line, ultralight carbon endurance road bike decked out with the best parts for a fast, high-performance ride. You get our highest-level OCLV Carbon frame with rear IsoSpeed, SRAM's new RED AXS electronic drivetrain, and OCLV Carbon wheels. Plus, it has an easy-access storage compartment for stowing ride essentials, and versatile 38c tire clearance to keep you floating on rough roads and light gravel.

Frame

800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle

Frame with Fork

800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle

Fork

Domane SLR carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle

Frame fit

Frame	800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
Fork	Domane SLR carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle
Frame fit	Endurance

Weight

Weight	56 - 7.48 kg / 16.5 lbs (with TLR sealant, no tubes)
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

E-system

Battery	SRAM eTap battery pack (with charger)

Drivetrain

Shifter	SRAM RED AXS E1
Front derailleur	SRAM RED AXS E1, braze-on
Rear derailleur	SRAM RED AXS E1, 36T max cog
*Crank	Size: 47, 50 SRAM RED AXS E1, power meter, 46/33, DUB, 165mm length
	Size: 52, 54 SRAM RED AXS E1, power meter, 46/33, DUB, 170mm length
	Size: 56, 58 SRAM RED AXS E1, power meter, 46/33, DUB, 172.5mm length
	Size: 60, 62 SRAM RED AXS E1, power meter, 46/33, DUB, 175mm length
Bottom bracket	SRAM DUB, T47 threaded, internal bearing
Cassette	SRAM RED XG-1290 E1, 10-36, 12 speed
Chain	SRAM RED E1, 12 speed
Max chainring size	1x: 48T, 2x: 52/36

Wheels

Wheel front	Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle
Wheel rear	Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle
Skewer front	Bontrager Switch thru axle, removable lever
Skewer rear	Bontrager Switch thru axle, removable lever
*Tire	Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
*Tire	Size: 47, 50, 52, 54, 56, 58, 60, 62 Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x30mm
Tire part	Bontrager TLR sealant, 180 ml/6 oz
Rim strip	Bontrager TLR
Max tire size	38mm without fenders, 35mm with fenders

Components

*Saddle	Size: 47, 50, 52 Verse Short Pro, carbon rails, 155mm width
*Saddle	Size: 54, 56, 58, 60, 62 Verse Short Pro, carbon rails, 145mm width
*Seatpost	Size: 47, 50, 52, 54, 56 KVF aero carbon seatpost, 20mm offset, 280mm length
*Seatpost	Size: 58, 60, 62 KVF aero carbon seatpost, 20mm offset, 320mm length
*Handlebar	Size: 47 Bontrager Pro IsoCore VR-SF, 38cm
	Size: 50, 52 Bontrager Pro IsoCore VR-SF, 40cm
	Size: 54, 56 Bontrager Pro IsoCore VR-SF, 42cm
	Size: 58, 60, 62 Bontrager Pro IsoCore VR-SF, 44cm
*Stem	Size: 47 Trek RCS Pro, -7 degree, 70mm length
	Size: 50 Trek RCS Pro, -7 degree, 80mm length
	Size: 52, 54 Trek RCS Pro, -7 degree, 90mm length
	Size: 56, 58 Trek RCS Pro, -7 degree, 100mm length
	Size: 60, 62 Trek RCS Pro, -7 degree, 110mm length
Brake rotor	SRAM Paceline X, rounded, centerlock, 160mm
Rotor size	Max brake rotor sizes: 160mm front & rear
