Checkmate SLR 7 AXS is a carbon gravel race bike built to toe the line and kick up dust on the long and rough road. To deliver the performance you crave on race day, Checkmate combines a lightweight aero design with IsoSpeed and new Gravel Race geometry that keeps you poised for the attack without eating up your energy. It's topped off with a SRAM Force XPLR AXS wireless drivetrain, carbon wheels, and Trek Aero RSL bar/stem for a lightweight build.
- Frame
-
800 Series OCLV Carbon, IsoSpeed, hidden fender mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12mm chamfered thru axle
- Fork
-
Checkmate SLR full carbon, tapered carbon steerer, hidden fender mounts, flat mount disc, 12x100mm thru axle
- Weight
- ML - 8.47 kg / 18.68 lbs (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
- Battery
-
SRAM AXS battery pack (with charger)
- Shifter
-
- Rear derailleur
-
SRAM Force XPLR AXS, 46T max cog
- *Crank
-
Size: XS, S
SRAM Force XPLR with AXS Power Meter, 42T, DUB Wide, 165mm length
Size: M, ML
SRAM Force XPLR with AXS Power Meter, 42T, DUB Wide, 170mm length
Size: L, XL
SRAM Force XPLR with AXS Power Meter, 42T, DUB Wide, 172.5mm length
- Bottom bracket
-
SRAM DUB Wide, T47 threaded, internal bearing
- Cassette
-
SRAM Force XPLR XG-1371, 10-46, 13 speed
- Max chainring size
- See service manual
- Wheel front
-
- Wheel rear
-
- Skewer front
-
- Skewer rear
-
- Tire
-
- Tire part
-
Bontrager TLR sealant, 180 ml/6 oz
- Rim strip
-
- Max tire size
- 45mm without fenders, 38mm with fenders (as measured, see manual for details)
- Seatpost
-
- *Handlebar/stem (integrated)
-
- Handlebar tape
-
- Brake rotor
-
SRAM Paceline X, rounded, centerlock, 160mm
- Rotor size
- Max brake rotor sizes: 180mm front & rear
