Orca isn’t just light. It is 6.7kg of climbing technology designed to change how you reach the top. The feeling of a bike this light and efficient is unbeatable, and this instant acceleration, vibration absorption and responsive handling come from a frame which knows where it needs to be light and where it needs to be stiff.

SPECIFICATIONS

FRAMESET

Frameset

Frame

Orbea Orca carbon OMX 2024, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.

Fork

Orbea Orca OMX ICR 2024, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.

Headset

FSA 1-1/2" Integrated Aluminium Cup

Drivetrain

Crankset

FSA Powerbox K-Force Team Edition 36x52t

Shifters

Shimano R9270

Cassette

Shimano Dura-Ace R9200 11-30t 12-Speed

Rear derailleur

Shimano Dura-Ace Di2 R9250

Front derailleur

Shimano Dura-Ace Di2 R9250

Chain

Shimano CN-9100

Cockpit

Handlebar

Vision Metron 5D ACR Integrated 3K, Reach 80mm, Drop 125

Stem

Integrated Vision Metron 5D ACR 3K, -6º

Brakes

Shimano R9270 Hydraulic Disc

Brakes Configuration

Wheels

Oquo Road Performance RP45LTD

Tyres

Vittoria Corsa Pro G2.0 TLR 700x28c

Front Wheel Axle

Orbea Thru Axle 12x100mm M12x2 P1 Lite

Rear Wheel Axle

Orbea Thru Axle 12x142mm M12x2 P1 Lite

Components

Seatpost

OC Performance XP10-S Carbon, 27.2mm, Setback 20

Saddle

Selle Italia SLR Boost Fill Carbon Rail Ø7x9 mm

Accessories

Handlebar Tape

Lizard DSP 2.5mm

GEOMETRY AND SIZE

1SEAT TUBE (C-T)

440

460

480

500

520

540

570

2TOP TUBE (EFF)

510,3

522,7

535,9

548,5

560,4

576,1

590

3HEAD TUBE

110,5

118,2

134,6

152,9

173,1

191,2

218,3

4CHAINSTAY

408

5BB HEIGHT (25-622)

268,5

270,5
